- Breadth-First Search의 약자
- 루트 노드에서 인접한 노드를 탐색하며 순회하는 탐색 방법
- BFS와 대조되는 DFS (깊이 우선 탐색)도 있다.
- Queue를 이용하여 구현하는게 일반적이다.
- Queue가 모두 소진될 때까지 루프하며 인접 노드들을 검색한다.
using System;
using System.Collections.Generic;
class Program
{
static void Main(string[] args)
{
MapController mapController = new MapController();
// 시작 좌표와 목적지 좌표를 매개변수로 넘겨준다.
mapController.BFS(0, 0, 5, 3);
}
}
public class MapController
{
// 탐색할 맵이다.
public int[,] maps = new int[,]
{
{0, 0, 0, 0, 0, 0 },
{0, 0, 1, 0, 0, 0 },
{0, 0, 1, 0, 0, 0 },
{0, 0, 1, 0, 0, 0 },
{0, 0, 1, 0, 0, 0 },
{0, 0, 0, 0, 0, 0 }
};
// 상 하 좌 우 방향을 나타낸다.
public int[,] direction = new int[,]
{
{ -1, 0 },
{ 1, 0 },
{ 0, -1 },
{ 0, 1 },
};
// 한번 들른 길인지 체크한다.
public bool[,] checkRoad = null;
// 탐색
public void BFS(int y, int x, int targetY, int targetX)
{
// 길 체크 플래그를 초기화해준다.
ClearCheckRoad();
// 가장 빠른길을 담을 노드를 선언한다.
BFSNode bestNode = null;
// 탐색하기 위한 BFSNode형 Queue를 만든다.
// 시작지점을 가리키는 Node를 만들어서 담는다.
// 시작지점은 한번 들른 길로서 체크한다.
Queue<BFSNode> queue = new Queue<BFSNode>();
queue.Enqueue(new BFSNode(y, x, null));
checkRoad[y, x] = true;
// 더이상 탐색할게 없을 때까지 루프한다.
while (queue.Count > 0)
{
// 노드를 가져온다.
BFSNode node = queue.Dequeue();
// 현재 노드가 목표 지점일 경우
if (node.Y == targetY && node.X == targetX)
{
// 가장 빠른길이 아직 없거나
// 현재 노드가 가장 빠른길일 경우 bestNode에 담는다.
// 이후 여기에 들어오는 Node들과 bestNode를 비교하여 가장 빠른 길을 담는다.
if (bestNode == null || (bestNode.PrevCount > node.PrevCount))
bestNode = node;
}
// 상 하 좌 우를 체크한다.
for (int i = 0; i < direction.GetLength(0); i++)
{
// 현재 노드의 위치 + (상or하or좌or우)
int dy = node.Y + direction[i, 0];
int dx = node.X + direction[i, 1];
// 좌표가 맵의 범위안에 있으며
// 갈 수 있는 길이고
// 한 번도 들른적 없는 길인 경우
if (CheckMapRange(dy, dx) && CheckMapWay(dy, dx) && !checkRoad[dy, dx])
{
// 찾은 길은 노드를 만들어 Queue에 담는다.
// 현재 노드는 찾은 길의 이전 노드로서 담는다.
BFSNode searchNode = new BFSNode(dy, dx, node);
queue.Enqueue(searchNode);
// 이 좌표는 한 번 들른 길로 체크한다.
checkRoad[dy, dx] = true;
}
}
}
while (bestNode.PrevCount > 0)
{
Console.WriteLine(string.Format("[{0},{1}]", bestNode.Y, bestNode.X));
// bestNode를 순회하며 해당 좌표를 콘솔로 찍어준다.
// [5,3]->[5,2]->[5,1]->[5,0]->[4,0]->[3,0]->[2,0]->[1,0] 순으로
bestNode = bestNode.PrevNode;
}
}
private bool CheckMapRange(int y, int x)
{
return (y >= 0 && y < maps.GetLength(0) &&
(x >= 0 && x < maps.GetLength(1)));
}
private bool CheckMapWay(int y, int x)
{
return maps[y, x] == 0;
}
private void ClearCheckRoad()
{
checkRoad = new bool[maps.GetLength(0), maps.GetLength(1)];
for (int i = 0; i < checkRoad.GetLength(0); ++i)
{
for (int j = 0; j < checkRoad.GetLength(1); ++j)
checkRoad[i, j] = false;
}
}
}
public class BFSNode
{
public int X { get; private set; }
public int Y { get; private set; }
public BFSNode PrevNode { get; private set; }
public int PrevCount { get; private set; }
public BFSNode(int y, int x, BFSNode prevNode)
{
Y = y;
X = x;
PrevNode = prevNode;
if (PrevNode == null)
{
// 이전 노드가 없으면 시작지점이기 때문에 Count는 0이다.
PrevCount = 0;
}
else
{
// 이전 노드가 있다면 이전노드의 '이전노드 갯수' + 1을 해준다.
// 목표지점에 해당하는 노드는 최종적으로
// 시작지점에서 목표지점까지의 노드 수가 담기게 된다.
PrevCount = PrevNode.PrevCount + 1;
}
}
}
